NEW Holset HX60W Turbo Truck Industrial Cummins QSX 15.0L Diesel 4955813 4047148
BRAND NEW GENUINE HOLSET TURBOCHARGER
This is a BRAND NEW GENUINE HOLSET TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 4047148
Interchangeable Number: 2836723, 2836725H, 2836760, 2836762H, 3593345, 3594488, 3595972, 3598762, 4024936, 4024937NX, 4024937RX, 4025272NX, 4025272RX, 4038498, 4041154, 4047149, 4047153H, 4089298NX, 4089298RX, 4089970NX, 4089970RX, 4955216NX, 4955216RX, 4955813NX, 4955813RX, 495608100, 4956082NX, 4956082RX
OEM Number: 2836725, 2836726, 2836727, 2836762, 3594490, 3594491, 3594492, 3595973, 3598763, 3598764, 3598765, 4024937, 4025272, 4038500, 4038501, 4038502, 4041155, 4041156, 4041157, 4047152, 4047153, 4047154, 4089298, 4089970, 4955216, 4955813, 4956081, 4956082
Turbo Model: HX60W
Manufacturer: Holset
Year: 2002-10
Engine: QSX, QSX15, QSX15 Tier 3
Engine Manufacturer: Cummins
Displacement: 15.0L
Emission Standard: Tier 3
Fuel: Diesel
Angle α (Compressor Housing): 270°
Angle β (Turbine Housing): 90/137/270°
Actuator Kit (Pneumatic): 4032304H (3593848, 3599836, 4030227, 4044633)
Back Plate: 3531917 (1250403300)
Bearing Housing: 3536802 (Oil Cooled)
CHRA: 4038499 (4038499H, 3768546)
Compressor Housing Kit: 4042570H
Compressor Wheel: 4040285 (3534650, 3534650H, 353465000)(Ind. 80 mm, Exd. 113 mm, Trim 8.74, 8+8 Blades, Super Back)
Gasket Kit: 3545577 (4681920000, 118097-0000, 468189-0000)
Heat Shield: 3519155 (18373)(351915500)
Repair Kit (Major): 4027881H (3545345, 3580568, 4027880)(1153060750)
Turbine Housing Kit: 4047157H
Turbine Wheel: 3533025 (3533025H, 353302500)(Ind. 97 mm, Exd. 86.3 mm, Trim 16.9, 12 Blades)(1153060435)
Turbocharger Kit: 4047153H
Application:
2002-10 Truck with Cummins QSX Engine
Industrial with Cummins QSX, QSX15 Engine
Various with Cummins CPL-3088, CM570 ECM (Electronics Control Unit) Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
This is a BRAND NEW GENUINE HOLSET TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 4047148
Interchangeable Number: 2836723, 2836725H, 2836760, 2836762H, 3593345, 3594488, 3595972, 3598762, 4024936, 4024937NX, 4024937RX, 4025272NX, 4025272RX, 4038498, 4041154, 4047149, 4047153H, 4089298NX, 4089298RX, 4089970NX, 4089970RX, 4955216NX, 4955216RX, 4955813NX, 4955813RX, 495608100, 4956082NX, 4956082RX
OEM Number: 2836725, 2836726, 2836727, 2836762, 3594490, 3594491, 3594492, 3595973, 3598763, 3598764, 3598765, 4024937, 4025272, 4038500, 4038501, 4038502, 4041155, 4041156, 4041157, 4047152, 4047153, 4047154, 4089298, 4089970, 4955216, 4955813, 4956081, 4956082
Turbo Model: HX60W
Manufacturer: Holset
Year: 2002-10
Engine: QSX, QSX15, QSX15 Tier 3
Engine Manufacturer: Cummins
Displacement: 15.0L
Emission Standard: Tier 3
Fuel: Diesel
Angle α (Compressor Housing): 270°
Angle β (Turbine Housing): 90/137/270°
Actuator Kit (Pneumatic): 4032304H (3593848, 3599836, 4030227, 4044633)
Back Plate: 3531917 (1250403300)
Bearing Housing: 3536802 (Oil Cooled)
CHRA: 4038499 (4038499H, 3768546)
Compressor Housing Kit: 4042570H
Compressor Wheel: 4040285 (3534650, 3534650H, 353465000)(Ind. 80 mm, Exd. 113 mm, Trim 8.74, 8+8 Blades, Super Back)
Gasket Kit: 3545577 (4681920000, 118097-0000, 468189-0000)
Heat Shield: 3519155 (18373)(351915500)
Repair Kit (Major): 4027881H (3545345, 3580568, 4027880)(1153060750)
Turbine Housing Kit: 4047157H
Turbine Wheel: 3533025 (3533025H, 353302500)(Ind. 97 mm, Exd. 86.3 mm, Trim 16.9, 12 Blades)(1153060435)
Turbocharger Kit: 4047153H
Application:
2002-10 Truck with Cummins QSX Engine
Industrial with Cummins QSX, QSX15 Engine
Various with Cummins CPL-3088, CM570 ECM (Electronics Control Unit) Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
BRAND NEW GENUINE HOLSET TURBOCHARGER
This is a BRAND NEW GENUINE HOLSET TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 4047148
Interchangeable Number: 2836723, 2836725H, 2836760, 2836762H, 3593345, 3594488, 3595972, 3598762, 4024936, 4024937NX, 4024937RX, 4025272NX, 4025272RX, 4038498, 4041154, 4047149, 4047153H, 4089298NX, 4089298RX, 4089970NX, 4089970RX, 4955216NX, 4955216RX, 4955813NX, 4955813RX, 495608100, 4956082NX, 4956082RX
OEM Number: 2836725, 2836726, 2836727, 2836762, 3594490, 3594491, 3594492, 3595973, 3598763, 3598764, 3598765, 4024937, 4025272, 4038500, 4038501, 4038502, 4041155, 4041156, 4041157, 4047152, 4047153, 4047154, 4089298, 4089970, 4955216, 4955813, 4956081, 4956082
Turbo Model: HX60W
Manufacturer: Holset
Year: 2002-10
Engine: QSX, QSX15, QSX15 Tier 3
Engine Manufacturer: Cummins
Displacement: 15.0L
Emission Standard: Tier 3
Fuel: Diesel
Angle α (Compressor Housing): 270°
Angle β (Turbine Housing): 90/137/270°
Actuator Kit (Pneumatic): 4032304H (3593848, 3599836, 4030227, 4044633)
Back Plate: 3531917 (1250403300)
Bearing Housing: 3536802 (Oil Cooled)
CHRA: 4038499 (4038499H, 3768546)
Compressor Housing Kit: 4042570H
Compressor Wheel: 4040285 (3534650, 3534650H, 353465000)(Ind. 80 mm, Exd. 113 mm, Trim 8.74, 8+8 Blades, Super Back)
Gasket Kit: 3545577 (4681920000, 118097-0000, 468189-0000)
Heat Shield: 3519155 (18373)(351915500)
Repair Kit (Major): 4027881H (3545345, 3580568, 4027880)(1153060750)
Turbine Housing Kit: 4047157H
Turbine Wheel: 3533025 (3533025H, 353302500)(Ind. 97 mm, Exd. 86.3 mm, Trim 16.9, 12 Blades)(1153060435)
Turbocharger Kit: 4047153H
Application:
2002-10 Truck with Cummins QSX Engine
Industrial with Cummins QSX, QSX15 Engine
Various with Cummins CPL-3088, CM570 ECM (Electronics Control Unit) Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
This is a BRAND NEW GENUINE HOLSET TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 4047148
Interchangeable Number: 2836723, 2836725H, 2836760, 2836762H, 3593345, 3594488, 3595972, 3598762, 4024936, 4024937NX, 4024937RX, 4025272NX, 4025272RX, 4038498, 4041154, 4047149, 4047153H, 4089298NX, 4089298RX, 4089970NX, 4089970RX, 4955216NX, 4955216RX, 4955813NX, 4955813RX, 495608100, 4956082NX, 4956082RX
OEM Number: 2836725, 2836726, 2836727, 2836762, 3594490, 3594491, 3594492, 3595973, 3598763, 3598764, 3598765, 4024937, 4025272, 4038500, 4038501, 4038502, 4041155, 4041156, 4041157, 4047152, 4047153, 4047154, 4089298, 4089970, 4955216, 4955813, 4956081, 4956082
Turbo Model: HX60W
Manufacturer: Holset
Year: 2002-10
Engine: QSX, QSX15, QSX15 Tier 3
Engine Manufacturer: Cummins
Displacement: 15.0L
Emission Standard: Tier 3
Fuel: Diesel
Angle α (Compressor Housing): 270°
Angle β (Turbine Housing): 90/137/270°
Actuator Kit (Pneumatic): 4032304H (3593848, 3599836, 4030227, 4044633)
Back Plate: 3531917 (1250403300)
Bearing Housing: 3536802 (Oil Cooled)
CHRA: 4038499 (4038499H, 3768546)
Compressor Housing Kit: 4042570H
Compressor Wheel: 4040285 (3534650, 3534650H, 353465000)(Ind. 80 mm, Exd. 113 mm, Trim 8.74, 8+8 Blades, Super Back)
Gasket Kit: 3545577 (4681920000, 118097-0000, 468189-0000)
Heat Shield: 3519155 (18373)(351915500)
Repair Kit (Major): 4027881H (3545345, 3580568, 4027880)(1153060750)
Turbine Housing Kit: 4047157H
Turbine Wheel: 3533025 (3533025H, 353302500)(Ind. 97 mm, Exd. 86.3 mm, Trim 16.9, 12 Blades)(1153060435)
Turbocharger Kit: 4047153H
Application:
2002-10 Truck with Cummins QSX Engine
Industrial with Cummins QSX, QSX15 Engine
Various with Cummins CPL-3088, CM570 ECM (Electronics Control Unit) Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
$1,450.75
Original: $4,145.00
-65%NEW Holset HX60W Turbo Truck Industrial Cummins QSX 15.0L Diesel 4955813 4047148—
$4,145.00
$1,450.75Description
BRAND NEW GENUINE HOLSET TURBOCHARGER
This is a BRAND NEW GENUINE HOLSET TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 4047148
Interchangeable Number: 2836723, 2836725H, 2836760, 2836762H, 3593345, 3594488, 3595972, 3598762, 4024936, 4024937NX, 4024937RX, 4025272NX, 4025272RX, 4038498, 4041154, 4047149, 4047153H, 4089298NX, 4089298RX, 4089970NX, 4089970RX, 4955216NX, 4955216RX, 4955813NX, 4955813RX, 495608100, 4956082NX, 4956082RX
OEM Number: 2836725, 2836726, 2836727, 2836762, 3594490, 3594491, 3594492, 3595973, 3598763, 3598764, 3598765, 4024937, 4025272, 4038500, 4038501, 4038502, 4041155, 4041156, 4041157, 4047152, 4047153, 4047154, 4089298, 4089970, 4955216, 4955813, 4956081, 4956082
Turbo Model: HX60W
Manufacturer: Holset
Year: 2002-10
Engine: QSX, QSX15, QSX15 Tier 3
Engine Manufacturer: Cummins
Displacement: 15.0L
Emission Standard: Tier 3
Fuel: Diesel
Angle α (Compressor Housing): 270°
Angle β (Turbine Housing): 90/137/270°
Actuator Kit (Pneumatic): 4032304H (3593848, 3599836, 4030227, 4044633)
Back Plate: 3531917 (1250403300)
Bearing Housing: 3536802 (Oil Cooled)
CHRA: 4038499 (4038499H, 3768546)
Compressor Housing Kit: 4042570H
Compressor Wheel: 4040285 (3534650, 3534650H, 353465000)(Ind. 80 mm, Exd. 113 mm, Trim 8.74, 8+8 Blades, Super Back)
Gasket Kit: 3545577 (4681920000, 118097-0000, 468189-0000)
Heat Shield: 3519155 (18373)(351915500)
Repair Kit (Major): 4027881H (3545345, 3580568, 4027880)(1153060750)
Turbine Housing Kit: 4047157H
Turbine Wheel: 3533025 (3533025H, 353302500)(Ind. 97 mm, Exd. 86.3 mm, Trim 16.9, 12 Blades)(1153060435)
Turbocharger Kit: 4047153H
Application:
2002-10 Truck with Cummins QSX Engine
Industrial with Cummins QSX, QSX15 Engine
Various with Cummins CPL-3088, CM570 ECM (Electronics Control Unit) Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
This is a BRAND NEW GENUINE HOLSET TURBOCHARGER. Exact same part sold at the dealership. This is an exact, direct fit OEM replacement turbo.
Fits the following:
Part Number: 4047148
Interchangeable Number: 2836723, 2836725H, 2836760, 2836762H, 3593345, 3594488, 3595972, 3598762, 4024936, 4024937NX, 4024937RX, 4025272NX, 4025272RX, 4038498, 4041154, 4047149, 4047153H, 4089298NX, 4089298RX, 4089970NX, 4089970RX, 4955216NX, 4955216RX, 4955813NX, 4955813RX, 495608100, 4956082NX, 4956082RX
OEM Number: 2836725, 2836726, 2836727, 2836762, 3594490, 3594491, 3594492, 3595973, 3598763, 3598764, 3598765, 4024937, 4025272, 4038500, 4038501, 4038502, 4041155, 4041156, 4041157, 4047152, 4047153, 4047154, 4089298, 4089970, 4955216, 4955813, 4956081, 4956082
Turbo Model: HX60W
Manufacturer: Holset
Year: 2002-10
Engine: QSX, QSX15, QSX15 Tier 3
Engine Manufacturer: Cummins
Displacement: 15.0L
Emission Standard: Tier 3
Fuel: Diesel
Angle α (Compressor Housing): 270°
Angle β (Turbine Housing): 90/137/270°
Actuator Kit (Pneumatic): 4032304H (3593848, 3599836, 4030227, 4044633)
Back Plate: 3531917 (1250403300)
Bearing Housing: 3536802 (Oil Cooled)
CHRA: 4038499 (4038499H, 3768546)
Compressor Housing Kit: 4042570H
Compressor Wheel: 4040285 (3534650, 3534650H, 353465000)(Ind. 80 mm, Exd. 113 mm, Trim 8.74, 8+8 Blades, Super Back)
Gasket Kit: 3545577 (4681920000, 118097-0000, 468189-0000)
Heat Shield: 3519155 (18373)(351915500)
Repair Kit (Major): 4027881H (3545345, 3580568, 4027880)(1153060750)
Turbine Housing Kit: 4047157H
Turbine Wheel: 3533025 (3533025H, 353302500)(Ind. 97 mm, Exd. 86.3 mm, Trim 16.9, 12 Blades)(1153060435)
Turbocharger Kit: 4047153H
Application:
2002-10 Truck with Cummins QSX Engine
Industrial with Cummins QSX, QSX15 Engine
Various with Cummins CPL-3088, CM570 ECM (Electronics Control Unit) Engine
*Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is finding the part number from the nameplate of your old turbo.
